А12202 Shower system
Shower system
Art. A12202
Description
Shower system with shower head
The set consists of
Shower head, Ø 208 mm, ABS-plastic, nozzles 80 pcs
Height-adjustable shower slide bar, Ø 25mm
1-spray hand shower with anti-lime system
Metal shower hose, 1500 mm
Shower mixer
Ceramic cartridge 35 mm, Sedal
Mounting kit
Materials

Brass, nickel-chrome plating, ABS-plastic

Bruttogewicht: 4

А12202 Shower system
You can add only 30 item to "My notepad"
Added
Almost in notepad
To «My notepad»
Add to notepad
You can add only 4 items from one category to compare
To «My notepad»
Added
Almost in compare
To «My notepad»
Add to compare
Shower head
Shower head
Shower head for shower systems A12202 is made of ABS-plastic. Nozzles are made of silicone with anti-lime protection system. Shower head is fastened to the cross bar with swivel joint connector which has inbuilt aerator for non-splashing water stream. It also allows you to change the angle of shower head from 0 to 22 degrees.
Height-adjustable shower slide bar
Height-adjustable shower slide bar
To adjust the height of A12202 you need to put out the upper part of the shower slide bar and fix it on the desired elevation using a coupling nut of the upper fastening.
Hand shower holder
Hand shower holder
Holder with variable angle that can be rotated by 180 degrees. Holder can be raised or lowered to any convenient height. Just push the button and move the holder along the slide bar.
1-spray hand shower
1-spray hand shower
1-spray hand shower with anti-lime system.
Ceramic swing diverter
Ceramic swing diverter
Ceramic swing diverter consists of two ceramic discs pressed tightly together. Ceramic discs have holes that depending on swing of diverter redirect the water flow from the spout to shower hose or shower head. For switching water to shower or spout rotate the diverter by 90 degrees.
Shower mixer
Shower mixer
Technical data: Working pressure - 1 - 5 Bar   Max working pressure - 9 Bar. Working temperature - 90 degrees max.
Installation
Installation
Shower system is easily fastened to the wall with a help of two eccentrics (connection to mixer) and one fastening element.
