Art. A13302 Thermo
Shower system with shower head
The set consists of
Shower head, Ø 250 mm, nozzles 135 pcs, ABS-plastic
Height-adjustable shower slide bar, Ø 25mm
3-spray hand shower with anti-lime system
Metal shower hose, 1500 mm
Thermostatic shower mixer
Metal shower hose, 1500 mm
Thermostatic cartridge Vernet
Non-return valves Neoperl
Non-return valves Neoperl
Swivel shower hose connector
Eccentrics with internal filters
Mounting kit
Materials Brass, nickel-chrome plating, ABS-plastic
Bruttogewicht: 3.7

To choose a store

The nearest retail store


Shower head

Shower head for shower systems A13302 Thermo is made of ABS-plastic. Nozzles are made of silicone with anti-lime protection system. Shower head is fastened to the cross bar with swivel joint connector which has inbuilt aerator for non-splashing water stream. It also allows you to change the angle of shower head from 0 to 22 degrees.

Hand shower holder

Holder with variable angle that can be rotated by 180 degrees. Holder can be raised or lowered to any convenient height. Just push the button and move the holder along the slide bar.

3-spray hand shower

3-spray hand shower with anti-lime system.

Height-adjustable shower slide bar

To adjust the height of A13302 Thermo you need to put out the upper part of the shower slide bar and fix it on the desired elevation using a coupling nut of the upper fastening.

Ceramic swing diverter

Ceramic swing diverter consists of two ceramic discs pressed tightly together. Ceramic discs have holes that depending on swing of diverter redirect the water flow from the spout to shower hose or shower head. For switching water to shower or spout rotate the diverter by 90 degrees.

Thermostatic shower mixer

A thermostatic mixer maintains the desired temperature automatically. Working temperature - opt. 20-50°,  max 65°. Working pressure - 1 - 5 Bar, opt. 3 Bar. Max working pressure - 5 Bar.


Shower system is easily fastened to the wall with a help of two eccentrics (connection to mixer) and one fastening element.
Please note that in thermostatic mixers hot water supply is on the left and cold water supply is on the right
